Fast-Turn CNC Milling Service
Our CNC Machining services and Milling prototype manufacturer capabilities enable us to produce the finest,highly accurate parts, full-functioning engineering prototypes, piece parts and injection molds. Fast turnaround and high accuracy on CNC prototypes can be achieved with a wide variety of materials. Using various materials during the concept stage of your prototype will allow your design team to closely simulate the final product appearance, but retain the freedom to make changes. Our highly trained CNC machinists have the experience to help point out any problem areas for future part production.


Fast-Turn CNC Turning Service
Our CNC turning capabilities indude live tooling which allows us to turn & mill at the same time so features like axial and radial holes, flats, grooves, and slots can be achieved.
CNC Turning enable high-speed turning of both plastics and metals from bar or block material. The turning process allows the production of complex external and internal geometries. Our CNC turning capability can make prototypes all the way through mass production parts.
Advantages of CNC Machining
• High precision
• Fast Turnaround
• Good repeatability
• Cost effective from prototypes to medium volumes
• Applicable for variety of plastic and metal materials
• Perfect approach to test design feasibility for optimization

Our CNC Material Options
Aluminum
· Aluminum 5082
· Aluminum 5083
· Aluminum 6060
· Aluminum 6061-T6
· Aluminum 6063
· Aluminum 6082
· Aluminum 7075-T651
· Aluminum 2024 MIC-6

Stainless Steel
· Stainless Steel 301
· Stainless Steel 303
· Stainless Steel 304
· Stainless Steel 316
· Stainless Steel 420
· Stainless Steel 440
· Stainless Steel 455
· Stainless Steel 465
· Stainless Steel 630 /17-4 PH

Tool Steel
· 1040 Steel
· # 45 Steel
· D2 Tool Steel
· P20 Tool Steel
· 718 Steel
· 738 Steel
· NAK 80 Tool Steel
· S136 Steel
· S235 Steel
· A2 Steel
· Mild Steel

Brass
Brass (H59/H62) has desirable properties for a number of applications, such as handles, automotive terminals and musical instruments.
It is low friction and has excellent electrical conductivity and its golden appearance make products looking excellent.

Copper
Copper (Cu-ETP) displays excellent thermal conductivity, electrical conductivity and plasticity. It is also highly ductile, corrosion resistant and can be easily welded.

Titanium
Titanium (Ti6AL-4V,TC4,TC5,Ti-6Al-4V-ELI) parts are frequently used in the aerospace, medical, military and marine industries.
Surgical equipment
Compressor blades
Airframe and space capsule components
Pressure vessels

Zinc Alloy
Zinc alloys are promising biodegradable metals due to their desirable corrosion characteristics and good biocompatibility. Zinc alloys are used for a range of applications including cosmetic vehicle parts, complex part housings, and fuel system components. At Marigold, we normally use Zamak 3 for Zinc alloy. It exhibits similar machinability to copper but are less abrasive to tooling. Automotive part shells and small electric motor casings are typical applications for this type of zinc.

Plastics
Plastics are also very popular option for CNC machining because of its wide choices, relatively lower price, and significantly faster machining time needed. We provide all common plastics for CNC machining services.
· ABS
· POM
· PMMA (Acrylic)
· PC
· PC+GF
· PEEK
· PP
· PE
· HDPE
· PA6
· PBT
· PEI
· PET
· PPS
· PPSU
· PTFE

Our CNC Surface Finishing Options
Polishing
Polishing is the process of creating a smooth and shiny surface, either through physical rubbing of the part or by chemical interference.
Polishing process can be applied for different metals such as Aluminum, Brass, Stainless Steel, Steel.

Sandblasting
Sand blasting results in parts with an identical surface with a matte texture. Used mainly for visual applications and can be followed by other surface treatments such as anodizing.
Sandblasting can be applied for various of materials of rapid prototypes, like ABS, Aluminum, Brass, Stainless Steel, Steel etc.

Anodizing
Anodizing is one of the most widely used finishing for rapid prototyping parts, it improves corrosion resistance, enhancing wear resistance and hardness, and protecting the metal surface. It is often applied in mechanical parts, aircraft, and automobile parts, precision instruments, etc.
At Marigold Rapid, we can offer different anodizing colors like clear, black, red, blue, gold, grey.

Painting
Painting is one of the most widely used surface treatment in industrial products or our daily life. With painting we can achieve different kinds of finishes, such as matt painting, glossy painting, textured painting, soft touch painting, and in theory any color is possible upon request.
At Marigold Rapid, we use both Pantone code and RAL code for color reference. And quite often customers also provide golden samples to us for our reference during production.
At

Powder Coating
Powder coating is a type of coating that is applied as a free-flowing, dry powder. Unlike conventional liquid paint which is delivered via an evaporating solvent, powder coating is typically applied electrostatically and then cured under heat or with ultraviolet light.
At Marigold Rapid, the most common colors we offer for powder coating is black and white, but we can basically offer any RAL or Pantone code colors upon request, and also glossy or matt finishes are available.

Electroplating
Electroplating is majorly applied to modify the surface features of an object (e.g corrosion protection, lubricity, abrasion). Some of the other common applications of electroplating involve:
· Improving wear resistance.
· Improving the thickness of the metal surface.
· Enhancing the electrical conductivity like plating a copper layer on an electrical component.
· Minimizing Friction
· Improving surface uniformity.

Our CNC Machining Tolerance
Our general tolerances for CNC machining of metals is DIN-2768-1-fine and for plastics DIN-2768-1-medium. Tolerances are greatly affected by part geometry and type of material. Our sales executives will consult with you on every project and we always aim to provide the best tolerance to you.
Type | Tolerance |
Linear dimension | +/-0.025 mm +/-0.001 inch |
Hole diameters(not reamed) | +/-0.025 mm +/-0.001 inch |
Shaft diameters | +/-0.025 mm +/-0.001 inch |
Part size limit | 950*550*480mm 37.0*21.5*18.5 inch |
QUALITY IS GUARANTEED
We pay a lot attention to quality control to ensure the parts we delivered are to your specs only this way can we build long term trustwortht cooperation with our customers.
Below are the measurements we take to ensure great quality parts:
Quote with DFM analysis
Contract review to distinguish any discrepancies
In process inspection
First article inspection
Before shipment AQL
inspection
Replace or remake at our costs if any quality reclamations

CNC Parts We Made
